Okay, imagine Traefik is the bouncer at a club (your web application). Usually, when someone comes to the door, the bouncer sees their face directly and knows who they are (their IP address).

Now, imagine there's a friendly assistant (another load balancer or proxy) standing before the bouncer. Instead of people going directly to the bouncer, they first talk to the assistant. The assistant checks their ID and then escorts them to the club.

The problem is, when the VIP (the web request) finally reaches the bouncer (Traefik), the bouncer only sees the assistant's face (the load balancer's IP address), not the actual VIP's face (the original user's IP address).

Proxy Protocol is like the assistant handing the bouncer a special note along with the VIP. This note says, "Hey, this person's real IP address is [original IP address], and they came in using [original port]."

Why is this important?

Knowing the real visitor: Your club (web application) might want to know who the actual visitors are for logging, security, or personalization. Without this note, it would only see all the traffic coming from the assistant.
Security: Some security measures might rely on the original IP address of the requester.

proxyProtocol: trustedIPs is like the bouncer having a list of assistants they trust.

You're telling Traefik: "Hey, only listen to these special notes (Proxy Protocol headers) if they come from these specific IP addresses (127.0.0.1/32 which is just your own machine, and 192.168.1.7). If a note comes from anyone else, ignore it because it might be someone trying to trick you!"

127.0.0.1/32: This means "trust the Proxy Protocol headers if they come from the same machine Traefik is running on." This is often used if you have a local proxy running on the same server.
192.168.1.7: This means "also trust Proxy Protocol headers if they come from the machine with the IP address 192.168.1.7" - this would likely be the IP address of your trusted load balancer or proxy.

Without Proxy Protocol

The user's browser makes a request to the load balancer. The load balancer then forwards that request to Traefik. From Traefik's perspective, the request looks like it's coming directly from the load balancer. The headers Traefik sees might look something like this:

GET / HTTP/1.1
Host: www.example.com
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64) ...
Accept: text/html,application/xhtml+xml,...
# ... other standard HTTP headers ...

Notice that Traefik only sees the load balancer's IP address (192.168.1.7) as the source of the connection. The original user's IP address (203.0.113.45) is lost.

With Proxy Protocol Enabled

When Proxy Protocol is enabled and correctly configured on both the load balancer and Traefik (with trustedIPs including the load balancer's IP), the load balancer will prepend a special "Proxy Protocol header" to the original HTTP request when forwarding it to Traefik.

The entire stream of data that Traefik receives will look something like this:

PROXY TCP4 203.0.113.45 50000 192.168.1.7 80\r\n
GET / HTTP/1.1
Host: www.example.com
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64) ...
Accept: text/html,application/xhtml+xml,...
# ... other standard HTTP headers ...

Let's break down the Proxy Protocol header:

PROXY: This is the magic word that tells the receiver (Traefik) that a Proxy Protocol header is coming.
TCP4: Indicates the protocol and address family of the original connection (TCP over IPv4). It could also be TCP6 for IPv6.
203.0.113.45: This is the source IP address of the original client (the user's browser).
50000: This is the source port of the original client's connection.
192.168.1.7: This is the destination IP address that the client connected to (the load balancer's IP).
80: This is the destination port that the client connected to (likely port 80 on the load balancer).
\r\n: These are the standard carriage return and line feed characters that terminate the Proxy Protocol header.

What Traefik Does

When Traefik receives this, and if the connection came from a trusted IP (like 192.168.1.7 in our example), it will:

Parse and understand the Proxy Protocol header.
Extract the original client's IP address (203.0.113.45) and port (50000).
Make this information available to its internal processing and to your backend applications, often through standard X-Forwarded-For and X-Forwarded-Proto headers that Traefik might add or modify based on the Proxy Protocol information.

Headers Seen by the Backend Application (Potentially):

Your backend application, behind Traefik, might then see headers like:

GET / HTTP/1.1
Host: www.example.com
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64) ...
Accept: text/html,application/xhtml+xml,...
X-Forwarded-For: 203.0.113.45
X-Forwarded-Proto: http  # Or https, depending on the original request to the LB
# ... other standard HTTP headers ...

Here, Traefik has used the information from the Proxy Protocol header to populate the X-Forwarded-For header with the original client's IP address.

In summary, a proxied request with Proxy Protocol includes a special initial line containing information about the original connection before the actual HTTP request headers. This allows Traefik (and other intermediaries that understand the protocol) to know the true source of the request.
