RPG-JS tutorial - Adding an intro GUI screen for selecting a Bitshares account

Continuing the RPG-JS theme, let's delve into some further development topics relating to Bitshares!

How to add an intro GUI screen!

I found myself requesting the user provide their Bitshares username at one point in my project using RPG-JS and figured that this info should be requested much earlier, so I worked on adding a GUI prompt for when the user first joins the map.

The starter project template showed us that we could easily show a message to the user when they join the map:

  async onJoinMap(player: RpgPlayer) {
    if (player.getVariable("AFTER_INTRO")) {
      return;
    }
    await player.showText("Welcome to the rpg js");
    player.setVariable("AFTER_INTRO", true);
  },

.
So, with a small change we can change the showText into a show GUI:

// Launch the intro GUI
async function playerIntro(player: RpgPlayer) {
  await player.gui("intro").open();
}

async onJoinMap(player: RpgPlayer) {
    if (player.getVariable("AFTER_INTRO")) {
      return;
    }
    await playerIntro(player);
    player.setVariable("AFTER_INTRO", true);
},

.
That's all the code that's needed to launch a GUI when the user first joins the map!

With regards to the content of the intro GUI, check it out!

<script>
import { defineComponent, computed, watchEffect, ref, onMounted, inject } from "vue";
import { useStore } from "@nanostores/vue";

import {
  $currentUser,
  setCurrentUser,
  $userStorage,
  removeUser,
} from "../nanostores/users.ts";
import { createUserSearchStore } from "../nanoeffects/UserSearch";

import "@shoelace-style/shoelace/dist/components/button/button.js";
import "@shoelace-style/shoelace/dist/components/dialog/dialog.js";
import "@shoelace-style/shoelace/dist/components/input/input.js";

export default defineComponent({
  name: "intro",
  setup() {
    const open = ref(true);

    const chain = ref();
    const method = ref();
    const inputText = ref();

    const inProgress = ref(false);
    const searchResult = ref(null);
    const searchError = ref(false);

    const storedUsers = useStore($userStorage);

    async function search() {
      if (!chain.value || !inputText.value) {
        console.log("Invalid search parameters..");
        return;
      }

      searchError.value = false;
      inProgress.value = true;

      const searchStore = createUserSearchStore([chain.value, inputText.value]);

      const unsub = searchStore.subscribe((result) => {
        if (result.error) {
          searchError.value = true;
          inProgress.value = false;
          console.error(result.error);
        }

        if (!result.loading) {
          if (result.data) {
            const res = result.data;
            searchResult.value = res;
            inProgress.value = false;
          }
        }
      });

      return () => {
        unsub();
      };
    }

    function handleCloseRequest(event) {
      if (event.detail.source === "overlay" || event.detail.source === "close-button") {
        event.preventDefault();
      }
    }

    return {
      // basic dialog functionality
      open,
      chain,
      handleCloseRequest,
      // mode and storage
      method,
      storedUsers,
      setCurrentUser,
      // account search functionality
      inputText,
      inProgress,
      searchError,
      searchResult,
      search,
    };
  },
});
</script>

<template>
  <div class="computer">
    <sl-dialog
      :open="open"
      label="Select a blockchain account to proceed!"
      class="dialog-overview"
      @sl-request-close="handleCloseRequest"
    >
      <div v-if="!chain">
        <p>Please select the blockchain you want to use.</p>
        <div class="smallGrid">
          <sl-button slot="footer" variant="neutral" @click="chain = 'bitshares'"
            >Bitshares
          </sl-button>
          <sl-button slot="footer" variant="neutral" @click="chain = 'bitshares_testnet'">
            Bitshares testnet
          </sl-button>
        </div>
      </div>

      <div v-if="chain && !method">
        <p>
          {{
            chain === "bitshares"
              ? "You can either search for a new or a previous Bitshares account"
              : "You can either search for a new or a previous Bitshares testnet account"
          }}
        </p>
        <p>How do you want to proceed?</p>
        <div class="smallGrid">
          <sl-button slot="footer" variant="neutral" @click="method = 'new'">
            Search for an account
          </sl-button>
          <sl-button slot="footer" variant="neutral" @click="method = 'existing'">
            Previously used accounts
          </sl-button>
          <sl-button slot="footer" variant="neutral" @click="chain = null">Back</sl-button>
        </div>
      </div>

      <div v-if="chain && method === 'new'">
        <p>
          {{
            chain === "bitshares"
              ? "Searching for a replacement Bitshares (BTS) account"
              : "Searching for a replacement Bitshares testnet (TEST) account"
          }}
        </p>
        <sl-input
          type="text"
          placeholder="Username"
          @input="
            inputText = $event.target.value;
            searchResult = null;
            searchError = false;
          "
          @keypress.enter="search"
        ></sl-input>

        <div class="smallGrid">
          <sl-button slot="footer" variant="primary" @click="search">Search</sl-button>
          <sl-button slot="footer" variant="neutral" @click="method = null">Back</sl-button>
        </div>
        <sl-divider v-if="searchResult"></sl-divider>
      </div>

      <div v-if="searchResult">
        <p>
          {{
            chain === "bitshares"
              ? "Found the following Bitshares (BTS) account!"
              : "Found the following Bitshares testnet (TEST) account!"
          }}
        </p>
        <p>{{ searchResult.name }} ({{ searchResult.id }})</p>
        <sl-button
          slot="footer"
          variant="primary"
          @click="
            setCurrentUser(searchResult.name, searchResult.id, searchResult.referrer, chain);
            open = false;
          "
        >
          Proceed with this account
        </sl-button>
      </div>

      <div v-if="chain && method === 'existing'">
        <p>
          {{
            chain === "bitshares"
              ? "Selecting a previously used Bitshares (BTS) account"
              : "Selecting a previously used Bitshares testnet (TEST) account"
          }}
        </p>
        <div
          v-if="
            storedUsers &&
            storedUsers.users &&
            storedUsers.users.length > 0 &&
            storedUsers.users.filter((user) => user.chain === chain)
          "
        >
          <p>Choose an account from the list below:</p>

          <sl-button
            v-for="user in storedUsers.users.filter((user) => user.chain === chain)"
            @click="
              setCurrentUser(user.username, user.id, user.referrer, chain);
              open = false;
            "
            :key="user.id"
            variant="neutral"
            style="margin: 5px"
          >
            {{ user.username }} ({{ user.id }})
          </sl-button>

          <sl-button slot="footer" variant="neutral" @click="method = null">Back</sl-button>
        </div>
        <div v-else>
          <p>No previously used accounts found, please use a new account.</p>
          <sl-button slot="footer" variant="neutral" @click="method = 'new'">
            Find account
          </sl-button>
        </div>
      </div>
    </sl-dialog>
  </div>
</template>

<style scoped>
sl-dialog::part(header) {
  padding-bottom: 5px;
}
sl-dialog::part(body) {
  padding-top: 5px;
}
.smallGrid {
  display: grid;
  grid-template-columns: repeat(2, 1fr);
  grid-gap: 5px;
  margin-top: 30px;
}
</style>

So with this GUI component we launch a dialog which can only be dismissed by selecting a Bitshares or Bitshares testnet account to use in the game.

Check it out:

This account select dialog functions very similarly to the account select component in the astro bitshares nft tool & astro market UI projects, just without the avatar following the mouse.

The chosen user and blockchain are stored in a persistent nanostore:

import { map } from "nanostores";
import { persistentMap } from "@nanostores/persistent";

type User = {
  username: string;
  id: string;
  chain: string;
  referrer: string;
};

/**
 * Declaring the current user map nanostore
 */
const $currentUser = map<User>({
  username: "",
  id: "",
  chain: "",
  referrer: "",
});

/**
 * Setting the current user in a non persistent nanostore map
 * @param username
 * @param id
 * @param referrer
 * @param chain
 */
function setCurrentUser(username: string, id: string, referrer: string, chain: string) {
  $currentUser.set({
    username,
    id,
    chain,
    referrer,
  });

  try {
    addUser(username, id, referrer, chain);
  } catch (e) {
    console.log(e);
  }
}

function eraseCurrentUser() {
  $currentUser.set({
    username: "",
    id: "",
    chain: "",
    referrer: "",
  });
}

type StoredUsers = {
  users: User[];
  lastAccount: User[];
};

/**
 * Declaring the persistent user store
 */
const $userStorage = persistentMap<StoredUsers>(
  "storedUsers:",
  {
    users: [],
    lastAccount: [],
  },
  {
    encode(value) {
      return JSON.stringify(value);
    },
    decode(value) {
      try {
        return JSON.parse(value);
      } catch (e) {
        console.log(e);
        return value;
      }
    },
  }
);

/**
 * Add an user to the persistent user store
 * @param username
 * @param id
 * @param chain
 */
function addUser(username: string, id: string, referrer: string, chain: string) {
  const users = $userStorage.get().users;
  const user = { username, id, referrer, chain };
  $userStorage.setKey("lastAccount", [user]);
  if (users.find((user) => user.id === id)) {
    //console.log("Using existing user");
    return;
  }
  const newUsers = [...users, user];
  $userStorage.setKey("users", newUsers);
}

/**
 * Removing a single user from the persistent user store
 * @param id
 */
function removeUser(id: string) {
  const users = $userStorage.get().users;
  const newUsers = users.filter((user) => user.id !== id);
  $userStorage.setKey("users", newUsers);

  const lastUser = $userStorage.get().lastAccount;
  if (lastUser && lastUser.length && lastUser[0].id === id) {
    $userStorage.setKey("lastAccount", []);
  }
}

export { $currentUser, setCurrentUser, eraseCurrentUser, $userStorage, addUser, removeUser };

This can be easily fetched within another GUI component via the following:

import { useStore } from "@nanostores/vue";

const currentUser = useStore($currentUser);
const storedUsers = useStore($userStorage);

Have fun implementing your own startup screen GUIs using the above technique!

---

Have any questions? Comment below!

---
