For over 7 Days I have no sharing of what has happened to me and what I have been doing in recent days. And to this day I have not finished our project because it requires a change and it has not been easy. As you can see below, I've done the Furniture Layout and Ceiling Layout but I need to change it again. Because the client sent an email and has the final approval signature of what room he wants for their little Coffee Shop.

This plan requires the right size of available items of Furniture to be used to make custom made cabinets and counters. I use a millimeter in AutoCAD instead of a centimeter to get the exact size. If the projection is needed by the client, to see what it will look like; I create Isometric View and Flat shots in AutoCAD so that the client can think and see the outcome.

The elevation is to see the front or part of the coffee shop or room and see what it looks like and its dimensions. This elevation is typical of the opposite side so there is no need to repeat the drawing if you see it in the plan. When the elevation is over, the next is the detail drawing, which is a bit difficult.

Detailed drawing requires a great deal of knowledge of the right-size of things. Because each of these sizes will be followed by carpenters, an architect needs to know the standard dimensions of objects such as MDF (wood), steel, door height, and other standard sizes.

This is just a simple section to show the wall partition and other items or furniture. What is important here is the dimensions of each furniture and the height of the walls. Some sections can be used in detail or blow-up detail even the elevations.

If you notice, I did not include the kitchen section and elevation because the kitchen-supplier will provide the details on it including the M.E.P for the hood extraction and calculation.

For everyone's knowledge. I'm not an architect and I'm not a registered architect or engineer. I only got it through experience and self-study. I had just graduated from high school and had just completed my 1st semester of Bachelor of Science in Marine Transportation. Nothing more and Nothing Less.
