Before starting I would like to tell that many resources have confirmed that this project is still going on and caused various natural disasters in Japan.
The High Frequency Active Auroral Research Program (HAARP) was initiated as an ionospheric research program jointly funded by the US Air Force, the U.S. Navy, the University of Alaska Fairbanks, and the Defense Advanced Research Projects Agency (DARPA).[1] It was designed and built by BAE Advanced Technologies (BAEAT). Its original purpose was to analyze the ionosphere and investigate the potential for developing ionospheric enhancement technology for radio communications and surveillance. As a university-owned facility HAARP is a high-power, high-frequency transmitter used for study of the ionosphere.
The most prominent instrument at HAARP is the Ionospheric Research Instrument (IRI), a high-power radio frequency transmitter facility operating in the high frequency (HF) band. The IRI is used to temporarily excite a limited area of the ionosphere. Other instruments, such as a VHF and a UHF radar, a fluxgate magnetometer, a digisonde (an ionospheric sounding device), and an induction magnetometer, are used to study the physical processes that occur in the excited region.
Work on the HAARP facility began in 1993. The current working IRI was completed in 2007; its prime contractor was BAE Systems Advanced Technologies. As of 2008, HAARP had incurred around $250 million in tax-funded construction and operating costs. In May 2014, it was announced that the HAARP program would be permanently shut down later in the year. After discussions between the parties, ownership of the facility and its equipment was transferred to the University of Alaska Fairbanks in August 2015.
HAARP is a target of conspiracy theorists, who claim that it is capable of "weaponizing" weather. Commentators and scientists say that advocates of this theory are "uninformed", as claims made fall well outside the abilities of the facility, if not the scope of natural science.
History.
The HAARP program began in 1990. Republican Ted Stevens, U.S. senator from Alaska, helped win approval for the facility,[7] whose construction began in 1993.
In early May 2013, HAARP was temporarily shut down, awaiting a change between contractors to operate the facility. In July 2013, HAARP program manager James Keeney said, "Defense Advanced Research Projects Agency (DARPA) is expected on site as a client to finish up some research in fall 2013 and winter 2014." The temporary shutdown was described as being due to "a contractor regime change." Ahtna, Incorporated, the Alaska Native corporation serving the region of Alaska where the HAARP site is located, was reportedly in talks to take over the facility administration contract from Marsh Creek, LLC.
In May 2014, the Air Force announced that the HAARP program would be shut down later in 2014. While experiments ended in the summer of 2014, the complete shutdown and dismantling of the facility was postponed until at least May 2015. In mid-August 2015 control of the facility and its equipment was turned over to the University of Alaska Fairbanks, which is making the facilities available for researchers on a pay-per-use basis.
Project overview.
The HAARP project directs a 3.6 MW signal, in the 2.8–10 MHz region of the HF (high-frequency) band, into the ionosphere. The signal may be pulsed or continuous. Effects of the transmission and any recovery period can be examined using associated instrumentation, including VHF and UHF radars, HF receivers, and optical cameras. According to the HAARP team, this will advance the study of basic natural processes that occur in the ionosphere under the natural but much stronger influence of solar interaction. HAARP also enables studies of how the natural ionosphere affects radio signals.
The insights gleaned at HAARP will enable scientists to develop methods to mitigate these effects to improve the reliability or performance of communication and navigation systems which would have a wide range of both civilian and military uses, such as an increased accuracy of GPS navigation and advances in underwater and underground research and applications. This may lead, among other things, to improved methods for submarine communication or an ability to remotely sense and map the mineral content of the terrestrial subsurface, and perhaps underground complexes, of regions or countries. The current facility lacks range to be used in regions like the oil-rich Middle East, according to one of the researchers involved, but the technology could be put on a mobile platform.[14]
The project was originally funded by the Office of Naval Research and jointly managed by the ONR and Air Force Research Laboratory, with principal involvement of the University of Alaska Fairbanks. Many other US universities and educational institutions were involved in the development of the project and its instruments, namely the University of Alaska Fairbanks, Stanford University, Penn State University (ARL), Boston College, UCLA, Clemson University, Dartmouth College, Cornell University, Johns Hopkins University, University of Maryland, College Park, University of Massachusetts Amherst, MIT, Polytechnic Institute of New York University, Virginia Tech and the University of Tulsa. The project's specifications were developed by the universities, who continued to play a major role in the design of future research efforts.
According to HAARP's original management, the project strove for openness, and all activities were logged and publicly available, a practice which continues under the University of Alaska Fairbanks. Scientists without security clearances, even foreign nationals, were routinely allowed on site, which also continues today. HAARP hosts an open house annually, during which time any civilian can tour the entire facility. In addition, scientific results obtained using HAARP are routinely published in major research journals (such as Geophysical Research Letters, or Journal of Geophysical Research), written both by university scientists (American and foreign) and by U.S. Department of Defense research lab scientists..
Research.
HAARP's main goal is basic science research in the uppermost portion of the atmosphere, termed the ionosphere. Essentially a transition between the atmosphere and the magnetosphere, the ionosphere is where the atmosphere is thin enough that the sun's X-rays and UV rays can reach it, but thick enough that there are enough molecules present to absorb those rays. Consequently, the ionosphere consists of a rapid increase in density of free electrons, beginning at ~70 km, reaching a peak at ~300 km, and then falling off again as the atmosphere disappears entirely by ~1,000 km. Various aspects of HAARP can study all of the main layers of the ionosphere.
The profile of the ionosphere is highly variable, changing constantly on timescales of minutes, hours, days, seasons, and years. This profile becomes even more complex near Earth's magnetic poles, where the nearly vertical alignment and intensity of earth's magnetic field can cause physical effects like the aurora.
The ionosphere is traditionally very difficult to measure. Balloons cannot reach it because the air is too thin, but satellites cannot orbit there because the air is too thick. Hence, most experiments on the ionosphere give only small pieces of information. HAARP approaches the study of the ionosphere by following in the footsteps of an ionospheric heater called EISCAT near Tromsø, Norway. There, scientists pioneered exploration of the ionosphere by perturbing it with radio waves in the 2–10 MHz range, and studying how the ionosphere reacts. HAARP performs the same functions but with more power and a more flexible and agile HF beam.
Some of the main scientific findings from HAARP include:
Generating very low frequency radio waves by modulated heating of the auroral electrojet, useful because generating VLF waves ordinarily requires gigantic antennas
Generating weak luminous glow (measurable, but below that visible with a naked eye) from absorbing HAARP's signal
Generating extremely low frequency waves in the 0.1 Hz range. These are next to impossible to produce any other way, because the length of an antenna is dictated by the wavelength of the signal it emits or receives.
Generating whistler-mode VLF signals that enter the magnetosphere and propagate to the other hemisphere, interacting with Van Allen radiation belt particles along the way
VLF remote sensing of the heated ionosphere
Research at the HAARP has included:
Plasma line observations
Stimulated electron emission observations
Gyro frequency heating research
Spread F observations (blurring of ionospheric echoes of radio waves due to irregularities in electron density in the F layer)
High velocity trace runs
Airglow observations
Heating induced scintillation observations
VLF and ELF generation observations[15]
Radio observations of meteors
Polar mesospheric summer echoes (PMSE) have been studied, probing the mesosphere using the IRI as a powerful radar, and with a 28 MHz radar and two VHF radars at 49 MHz and 139 MHz. The presence of multiple radars spanning both HF and VHF bands allows scientists to make comparative measurements that may someday lead to an understanding of the processes that form these elusive phenomena.
Research into extraterrestrial HF radar echos: the Lunar Echo experiment (2008).[16][17]
Testing of Spread Spectrum Transmitters (2009)
Meteor shower impacts on the ionosphere
Response and recovery of the ionosphere from solar flares and geomagnetic storms
The effect of ionospheric disturbances on GPS satellite signal quality
Producing high density plasma clouds in Earth's upper atmosphere[18]
Research conducted at the HAARP facility has allowed the US military to perfect communications with its fleet of submarines by sending radio signals over long distances.[19][20]
Instrumentation and operation
The main instrument at HAARP is the Ionospheric Research Instrument (IRI). This is a high-power, high-frequency phased array radio transmitter with a set of 180 antennas, disposed in an array of 12x15 units that occupy a rectangle of about 30–40 acres (12–16 hectares).[21][22] The IRI is used to temporarily energize a small portion of the ionosphere. The study of these disturbed volumes yields important information for understanding natural ionospheric processes.
During active ionospheric research, the signal generated by the transmitter system is delivered to the antenna array and transmitted in an upward direction. At an altitude between 70 to 350 km (43 to 217 mi) (depending on operating frequency), the signal is partially absorbed in a small volume several tens of kilometers in diameter and a few meters thick over the IRI. The intensity of the HF signal in the ionosphere is less than 3 µW/cm², tens of thousands of times less than the Sun's natural electromagnetic radiation reaching the earth and hundreds of times less than even the normal random variations in intensity of the Sun's natural ultraviolet (UV) energy which creates the ionosphere. The small effects that are produced, however, can be observed with the sensitive scientific instruments installed at the HAARP facility, and these observations can provide information about the dynamics of plasmas and insight into the processes of solar-terrestrial interactions.[23]
Each antenna element consists of a crossed dipole that can be polarized for linear, ordinary mode (O-mode), or extraordinary mode (X-mode) transmission and reception.[24][25] Each part of the two section crossed dipoles are individually fed from a specially designed, custom-built transmitter that operates at very low distortion levels. The Effective Radiated Power (ERP) of the IRI is limited by more than a factor of 10 at its lower operating frequencies. Much of this is due to higher antenna losses and a less efficient antenna pattern.
The IRI can transmit between 2.7 and 10 MHz, a frequency range that lies above the AM radio broadcast band and well below Citizens' Band frequency allocations. However, HAARP is licensed to transmit only in certain segments of this frequency range. When the IRI is transmitting, the bandwidth of the transmitted signal is 100 kHz or less. The IRI can transmit in continuous waves (CW) or in pulses as short as 10 microseconds (µs). CW transmission is generally used for ionospheric modification, while transmission in short pulses frequently repeated is used as a radar system. Researchers can run experiments that use both modes of transmission, first modifying the ionosphere for a predetermined amount of time, then measuring the decay of modification effects with pulsed transmissions.
There are other geophysical instruments for research located at the HAARP facility. Some of them are:
A fluxgate magnetometer built by the University of Alaska Fairbanks Geophysical Institute, available to chart variations in the Earth's magnetic field. Rapid and sharp changes of the magnetic field may indicate a geomagnetic storm.
A digisonde that can provide ionospheric profiles, allowing scientists to choose appropriate frequencies for IRI operation. The HAARP makes current and historic digisonde information available online.
An induction magnetometer, provided by the University of Tokyo, that measures the changing geomagnetic field in the Ultra Low Frequency (ULF) range of 0–5 Hz.
The facility is powered by a set of five (5) 2500 kilowatt generators being driven by EMD 20-645-E4 diesel locomotive engines.
Site
The project site (62°23′30″N 145°09′03″W) is north of Gakona, Alaska just west of Wrangell-Saint Elias National Park. An environmental impact statement led to permission for an array of up to 180 antennas to be erected.[26] HAARP was constructed at the previous site of an over-the-horizon radar (OTH) installation. A large structure, built to house the OTH now houses the HAARP control room, kitchen and offices. Several other small structures house various instruments.
The HAARP site was constructed in three distinct phases:[27]
The Developmental Prototype (DP) had 18 antenna elements, organized in three columns by six rows. It was fed with a total of 360 kilowatts (kW) combined transmitter output power. The DP transmitted just enough power for the most basic of ionospheric testing.
The Filled Developmental Prototype (FDP) had 48 antenna units arrayed in six columns by eight rows, with 960 kW of transmitter power. It was fairly comparable to other ionospheric heating facilities. This was used for a number of successful scientific experiments and ionospheric exploration campaigns over the years.
The Final IRI (FIRI) is the final build of the IRI. It has 180 antenna units, organized in 15 columns by 12 rows, yielding a theoretical maximum gain of 31 dB. A total of 3.6 MW of transmitter power will feed it, but the power is focused in the upward direction by the geometry of the large phased array of antennas which allow the antennas to work together in controlling the direction. As of March 2007, all the antennas were in place, the final phase was completed and the antenna array was undergoing testing aimed at fine-tuning its performance to comply with safety requirements required by regulatory agencies. The facility officially began full operations in its final 3.6 MW transmitter power completed status in the summer of 2007, yielding an effective radiated power (ERP) of 5.1 Gigawatts or 97.1 dBW at maximum output. However, the site typically operates at a fraction of that value due to the lower antenna gain exhibited at standard operational frequencies.
