SwiftAnimations

Description

SwiftAnimations it's a library created to visualize changes to array. It might be a helpful tool for studying sorting algorithms.

You can find out source code with a playground here:
https://github.com/izotx/SwiftAnimations

The source code contains example of using the library with bubble sort.

Usage

Library comes with several handy methods for visualizing changes:

swapElements // Responsible for swapping elements in array
selectElements // Selecting and deselecting
insertAtIndex moves element from index a to b and shifts array
up, down, rightLeft, for more granular control over animations

Each of the methods creates and adds an animation to the list of animations.

Here is original Bubble Sort code copied from awesome Swift Algorithms Club: https://github.com/raywenderlich/swift-algorithm-club

func originalBubbleSort(_  array:inout [Int]){
    for _ in 0..<array.count {
        for j in 1..<array.count {
            if array[j] < array[j-1] {
                let tmp = array[j-1]
                array[j-1] = array[j]
                array[j] = tmp
            }
        }
    }
}

In order to use library you have to:

1. Create an instance of the library

    let visualizer:ArrayAnimationView<Int> = ArrayAnimationView(frame: CGRect(x: 0, y: 0, width: 380, height: 50))

1. Add it to the view

    self.view.addSubview(visualizer)

1. Display array

    var a = [3,2,0,8,5,10,6,9]
    visualizer.displayArray(a)

1. Create an extension with animation:
   The key point here is recognize what algorithm is doing, and visualize it. For example the code below:

   let tmp = array[j-1]
    array[j-1] = array[j]
    array[j] = tmp

is performing swap of two elements of the array. The code below is a full example of animations

1. Animate changes
   visualizer.resetAnimations()
   visualizer.bubbleSort(&a)
   visualizer.animateChanges()

extension  ArrayAnimationView{
    func bubbleSort(_  array:inout [Int]){
        for _ in 0..<array.count {
            for j in 1..<array.count {
                //Compare two elements: so slide down
                if array[j] < array[j-1] {
                    let tmp = array[j-1]
                    array[j-1] = array[j]
                    array[j] = tmp
                    swapElements(arrayElements[j], arrayElements[j-1], j, j-1)
                }
                else{

                selectElements([arrayElements[j], arrayElements[j-1]], [true,true])
                down([arrayElements[j], arrayElements[j-1]])
                up([arrayElements[j], arrayElements[j-1]])

                selectElements([arrayElements[j], arrayElements[j-1]], [false,false])

                }
            }
        }
    }
}
